Description

Features:

• For single phase alternating current
• Powerful and fast cutting for profiles, pipes and rods made of steel, cast iron, aluminium and other non-ferrous metals.
• Motor and gear with ball bearing for high loads
• Spindle lock for easy disc change
• Quick clamping device with variable mitre conversion from -15° up to 45°
• Easy to transport due to built-in handle and locking device
• High safety thanks to swivelling cutting guard
• Storage for double-ended wrench at the machine table
• Safe working thanks to adjustable spark guide plate
• Adjustable cutting depth limiter

Characteristics

• Grinding wheels (Ø x bore): 355 x 25.4 mm / 14 x 1 “
• Torque: 18 Nm / 160 in-lbs
• No-load speed: 4000 /min
• Rated input power: 2300 W
• Cutting capacity steel bars: 65 mm / 2 1/2 “
• Cutting capacity tubes: 125 mm / 5 “
• Cutting capacity steel sections: 115 x 130 mm / 4 1/2 x 5 1/8 “
• Maximum opening of vice jaws: 238 mm / 9 3/8 “
• Dimensions of the base plate: 468 x 282 mm / 18 7/16 x 11 3/32 “
• Transport height: 400 mm / 15 3/4 “
• Weight: 16.9 kg / 37 lbs
• Cable length: 2.7 m / 9 ft

Noise emission

• Sound pressure level: 91 dB(A)
• Sound power level (LwA): 104 dB(A)
• Uncertainty of measurement K: 3 dB(A)
